H501-02 Single-Point Weighing Load Cell

The Bonida H501-02 is a single-point weighing load cell for compact weighing platforms and equipment integration. Verified technical specifications (source catalog page 24): • Capacity: 80, 150, 200, 300, 600 g; 1, 2, 3 kg • Rated output: 0.8 ±15% mV/V; 2.0 ±20% mV/V • Zero balance: ±0.02 mV/V • Creep: 0.02% F.S. • Non-linearity: 0.02% F.S. • Hysteresis: 0.02% F.S. • Repeatability: 0.02% F.S. • Input impedance: 410 ±15 Ω • Output impedance: 350 ±5 Ω • Temperature effect on sensitivity: 0.02% F.S./10°C • Temperature effect on zero: 0.03% F.S./10°C • Insulation resistance: ≥5000 MΩ/100 VDC • Recommended excitation: 5–12 VDC • Maximum excitation: 15 VDC • Compensated temperature range: -10 to 40°C • Operating temperature range: -20 to 60°C • Safe overload: 150% F.S. • Ultimate overload: 200% F.S. • Cable: Ø3 × 0.3 m • Maximum scale size: 100 × 100 mm • Maximum scale size for 80 g capacity: 40 × 40 mm Public pricing is not displayed. Please submit an RFQ to confirm the required capacity, quantity, integration details and lead time.
