H701-01 Compact Tension Sensor

Compact tension sensor for web tension, wire tension and automation equipment. Available capacities: 10, 20, 50 and 100 N. Accuracy class: 0.05% FS. Rated output: 2.0 +/-0.2 mV/V. Nonlinearity, hysteresis, repeatability and creep: +/-0.05% FS. Recommended excitation: 5-10 VDC; maximum 15 VDC. Operating temperature: -20 to 60 C. Safe overload: 120% FS; ultimate overload: 150% FS. Ingress protection: IP66. Available from Bonida for industrial integration and custom supply. Final range, installation arrangement and wiring should be confirmed during RFQ review.
